Honda BF75D - T Type

108
OPERATION
Tilt up the outboard motor using the
tilt lock lever when mooring the boat.
Move the shift lever or the remote
control lever to the NEUTRAL
position and stop the engine before
tilting up the outboard motor.
Before tilting up, leave the outboard
motor in the running position for one
minute after stopping the engine to
drain the water from inside the
engine.
1. Raise the outboard motor as full as
it goes using the power trim/tilt
switch.
2. Move the tilt lock lever to the
LOCK position and lower the
outboard motor until the lock lever
contacts the stern bracket.
3. Press the DN (down) of the power
trim/tilt switch and fully shorten
the trim rods.
4. To tilt down, raise the outboard
motor as far as it goes using the
power trim/tilt switch, move the tilt
lock lever to the FREE position.
TRIM RODS
Moorage (T type)
TILT LOCK LEVER TILT LOCK LEVER
FREE
LOCK
