23
CONTROLS AND FEATURES (H type)
Throttle Grip
Turn the grip clockwise or
counterclockwise to adjust the engine
speed. Turning the grip in the
direction shown by arrow increases
the engine speed.
The curve on the grip indicates the
engine speed.
Throttle Friction Adjuster
The throttle friction adjuster adjusts
resistance to throttle grip rotation.
Turn the adjuster clockwise to
increase friction for holding a throttle
setting while cruising.
Turn the adjuster counterclockwise to
decrease friction for easy throttle grip
rotation.
THROTTLE GRIP
THROTTLE
INDICATOR
FAST SLOW
START
THROTTLE FRICTION ADJUSTER
RELEASE
FIX
THROTTLE GRIP
