Honda BF75D - R Type Controls and Operation

25
CONTROLS AND FEATURES (H type)
The engine does not start unless the
emergency stop switch clip is set on
the emergency stop switch.
Store the spare emergency stop
switch clip in the tool bag.
Use the spare emergency stop switch
clip to make the disabled engine start
when the emergency stop switch
lanyard is not available as, for
example, when the operator falls
overboard.
Steering Friction Adjusting Knob
Use the steering friction adjusting
knob to adjust the tiller handle
friction. Turning it clockwise
increases friction and turning it
counterclockwise decreases friction.
SPARE EMERGENCY
STOP SWITCH CLIP
STEERING FRICTION
ADJUSTING KNOB
To decrease
friction
To incre a se
friction
