Honda BF75D - Engine Cover Fixing Lever; Tachometer (Equipped Type or Optional Equipment); Fuel Filler Cap (Equipped Type)

44
CONTROLS AND FEATURES (Common)
Engine Cover Fixing Lever
(Front/Rear)
Latch/unlatch the engine cover fixing
lever to install or remove the engine
cover.
Tachometer
(equipped type or optional
equipment)
The tachometer shows the engine
speed in revolutions per minute.
Fuel Filler Cap (equipped type)
(with vent knob)
The fuel filler cap vent knob controls
air entering and leaving the fuel tank.
When refilling the fuel tank, turn the
vent knob counterclockwise to open
and remove the fuel filler cap.
Turn the vent knob clockwise and
close it securely before transporting
or storing the fuel tank.
ENGINE COVER
FIXING LEVER
(front/rear)
UNLOCK
LOCK
TACHOMETER
FUEL FILLER CAP VENT KNOB
FUEL
FILLER CAP
OPEN
CLOSE
