131
MAINTENANCE
4. Remove the 6 × 25 mm flange bolt.
Disconnect the connector by
pushing the lock tab and remove
the ignition coil.
5. Remove the spark plug using the
plug wrench, box wrench and the
screwdriver (accessories).
6. Inspect the spark plugs.
(1) If the electrodes are heavily
corroded or carbon-soiled,
clean with a wire brush.
(2) Replace a spark plug if the
central electrode is worn.
The spark plug can wear out in
different ways.
If the sealing washer shows
signs of wear, or if the
insulators are cracked or
chipped, replace the spark
plugs.
6 × 25mm
FLANGE BOLT
CONNECTOR
LOCK TAB
IGNITION
COIL
BOX WRENCH
PLUG WRENCH
New plug Plug needing
replacement
