COMPONENT IDENTIFICATION
TOP-MOUNT TYPE (R3 type)
(DUAL OUTBOARD MOTOR TYPE)
REMOTE CONTROL LEVER
(SINGLE OUTBOARD MOTOR TYPE)
POWER TRIM/
TILT SWITCH
FAST IDLE BUTTON
REMOTE CONTROL LEVERS
POWER TRIM/TILT
SWITCH (RIGHT)
POWER TRIM/TILT
SWITCH (LEFT)
R3 type:
SPARE EMERGENCY
STOP SWITCH CLIP
Store the spare
emergency stop
switch clip in the
tool bag.
(for TOP-MOUNT DUAL type)
SWITCH PANEL (optional equipment)
(PANEL-MOUNT, TOP-MOUNT)
BUZZER
ENGINE
SWITCH
EMERGENCY
STOP SWITCH
EMERGENCY STOP SWITCH CLIP
EMERGENCY STOP SWITCH LANYARD
INDICATORS
(Oil pressure,
Overheat, ACG,
PGM-FI)
FAST IDLE BUTTON
