10
CONTROLS
HONDA FC600 (E) xxxxxxxxxxxx -10-
CONTROLS
Fuel Valve
The fuel valve opens and closes
the connection between the fuel
tank and the carburetor.
The fuel valve must be in the ON
position for the engine to run.
After stopping the engine, turn the
fuel valve to the OFF position.
Choke Lever
The choke lever opens and closes
the choke valve in the carburetor.
The CLOSED position enriches
the fuel mixture for starting a cold
engine.
The OPEN position provides the
correct fuel mixture for operation
after starting and for restarting a
warm engine.
Engine Switch
The engine switch controls the
ignition system.
OFF — Stops the engine.
ON
—
Running position.
FUEL
VALVE
ON
OFF
OPEN
CLOSE
CHOKE LEVER
ON
OFF OFF
ENGINE SWITCH
