SERVICING YOUR TILLER
HONDA FC600 (E) xxxxxxxxxxxx -28-
ENGINE OIL LEVEL CHECK
Check the engine oil level with the tiller on a level surface and the engine
stopped.
1. Remove the oil filler cap/dipstick and wipe it clean.
2. Insert and remove the dipstick without screwing it into the filler neck.
Check the oil level shown on the dipstick.
3. If the oil level is low, fill to the top of the oil filler neck with the
recommended oil (see page 30).
4. Screw in the filler cap/dipstick securely.
OIL FILLER NECK
OIL FILLER CAP/DIPSTICK
UPPER LIMIT
LOWER LIMIT
