CONTROLS
HONDA FC600 (E) xxxxxxxxxxxx -12-
Clutch Lever
The clutch lever engages and
disengages the transmission that
drives the tines.
Drag Bar
The drag bar controls tilling depth
and should always be used when
tilling. It enables you to compensate
for the hardness of the soil. Ideal
drag bar height will depend on the
type of soil being tilled and soil
conditions at the time of tilling. In
general, the drag bar should be
adjusted so that the tiller is tilted
slightly backward (see page 21).
CLUTCH LEVER
ENGAGED
DISENGAGED
DRAG BAR
