11
CONTROLS
HONDA FC600 (E) xxxxxxxxxxxx -11-
Starter Grip
Pulling the starter grip operates the
recoil starter to crank the engine
for starting.
Throttle Lever
The throttle lever controls engine
speed.
Moving the throttle lever in the
directions shown makes the
engine run faster or slower.
Tine speed is controlled by
adjusting the throttle lever.
At maximum throttle position, the
tines will rotate at the highest
speed.
Moving the throttle lever toward
the idle position will decrease the
tine speed.
Handlebar Height Adjuster
Handlebar height can be adjusted
to match operator height.
For normal tilling, the most
comfortable operator position is
with the handlebars at waist
height.
STARTER GRIP
THROTTLE
LEVER
FAST SLOW
HANDLEBAR
HEIGHT
ADJUSTER
HANDLEBAR
