CONTROLS
HONDA FC600 (E) xxxxxxxxxxxx -13-
Front Wheel
The front wheel is used to help move the tiller from one place to another. Lift
the tiller by the handlebars to roll the tiller on the front wheel. Return the
wheel to the raised position before tilling. Always stop the engine before
lowering or raising the wheel.
Hitch Box
Use a hitch pin as shown below to attach the drag bar or attachments to the
hitch box.
Tilling position.
FRONT WHEEL
Transport position.
HITCH BOX
HITCH PIN
