Honeywell Design and Application User Manual

Section 17 - Retrofit and Upgrades
63-8594-02 Honeywell Economizers 200
Enthalpy
Economizers
Sensor Comments Can be replaced with
C7400A1004 Standard
C7400A1012 OEM York #10125 C7400A1004
C7400A1020 Use with H705 only C7400A1004
C7400A1038 OEM Lennox #54G4401 C7400A1004
C7400A1046 OEM Carrier #HH57AC078A C7400A1004
C7400A1053 OEM Bard #8602-046 C7400A1004
Economizer Comments Can be replaced with
H205A All models
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000 +
actuator (See actuator section)
H705A All models
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000 +
actuator (See actuator section)
W6210A All models
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000 + series
72 actuator
W6215A1008 Standard
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000 + series
72 actuator
W7210A All models
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000 + series
72 actuator
W7212A1009 All models
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000
W7215A1006 All models
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000
W7215B1004 With outdoor IAQ
No replacement
W7299A1005 All models
W7220A1000 (JADE
TM
) +
C7250A1001 + C7400S1000
+M7215A1008
W7340A1004 OEM Trane Standard W7340C1000
W7340A1012 With wire harness W7340C1000
W7340A1020 W7340C1000
W7340B1002 OEM Trane #X1365108202 W7340C1000
W7340C1000 OEM Trane Standard #X1365108203
W7345A1009 OEM Trane W7345B1001
W7345B1001 OEM Trane
Standard W7340A1004 + M7215A1016
W7399A1004 W7399C1010
