Honeywell Design and Application User Manual

Section 8- W6215, W7215 And W7460 Economizer Modules
63-8594-02 Honeywell Economizers 76
Outdoor Air Content Sensor
The purpose of the DCV sensor is different
from that of the outdoor air content sensor. On
the economizer modules equipped with
outdoor air content sensors the purpose of the
sensor is to keep the outside air dampers at a
minimum position if the outdoor air is above its
setpoint threshold. Alarm contacts on the
economizer module will close if both the
outdoor and indoor air (DCV) signals are
above their respective setpoint thresholds.
Outdoor Air
Content
Sensor DCV Mixed Air Damper Actuator
Outdoor Air
Content Sensor
Light
Alarm
Contacts
Below
Setpoint
Below
Setpoint
Modulation based on signal from mixed air
temperature sensor.
Off Open
Above
Setpoint
Modulation between minimum and maximum
positions based on signal from either mixed air
or indoor air content sensors, whichever signal
is higher.
Off Open
Above
Setpoint
Below
Setpoint
Closed fully. On Open
Above
Setpoint
Modulation based on signal from mixed air
temperature sensor. Terminals labeled Alarm
made to energize warning light, audio alarm or
air cleaner.
On Closed
