Honeywell Design and Application User Manual

Section 17 - Retrofit and Upgrades
203 Honeywell Economizers 63-8594-02
W7220 JADE
TM
Y-Pack Table
Dry Bulb Changeover Y packs Y Pack Components
Dry Bulb with black motor
Y7220A7215 Includes
Logic Module W7220A1000
OAT sensor C7250A1001
MAT Sensor C7250A1001
Black Motor M7215A1008
Dry Bulb w/non-communicating DCA
YL7220A7503
Logic Module W7220A1000
OAT sensor C7250A1001
MAT Sensor C7250A1001
DCA OA MS7503A2030
Dry Bulb w/communicating 27 lb-in DCA
YL7220AJ3103
Logic Module W7220A1000
OAT sensor C7250A1001
MAT Sensor C7250A1001
DCA OA MS3103J1030
Dry Bulb w/communicating 44 lb-in DCA
YL7220AJ3105
Logic Module W7220A1000
OAT sensor C7250A1001
MAT Sensor C7250A1001
DCA OA MS3105J3030
Dry Bulb w/communicating 27 lb-in DCA and CO2
wall sensor without a display
YL7220ACW3103
Logic Module W7220A1000
OAT sensor C7250A1001
MAT Sensor C7250A1001
DCA OA MS3103J1030
CO2 sensor C7632A1004
Economizer Logic Module Logic Module W7220A1000
SENSORS
Mixed Air or Outdoor Air Temperature Sensor MAT or OAT sensor C7250A1001
Outdoor Air Enthalpy Sensor OAE C7400S1000
Wall Mount CO2 sensor with fixed settings CO2 sensor C7632A1004
Wall Mount CO2 sensor with selectable settings CO2 sensor C7232A1016
Duct Mount CO2 sensor with selectable settings CO2 sensor C7232B1014
ACTUATORS
Black footmounted motor Black motor M7215A1008
Non-communicating DCA 27 lb-in DCA 27 lb-in MS7503A2030
Communicating DCA 27 lb-in DCA 27 lb-in MS3103J1030
Communicating DCA 44 lb-in DCA 44 lb-in MS3105J3030
