Honeywell DPR180 User Manual

4-114
4. CONFIGURATION
4.5.3 Information about printing
• You can stop the printing at any time by pressing the SET UP or DISPLAY keys. All other keys are not
active.
• During the printing, a message (IN PROGRESS) is shown on the lower display, indicating the current
action.
• At the end of the printing, the initial messages are displayed again and the keys are reactivated.
• The data is printed in reverse order so that you can read it in a logical order from top to bottom when
completed.
4.5.4 WARNING
• During the printing of one sub-matrix, it is possible to print all the lines or only a few lines. In both cases,
these lines are consecutive.
• Some sub-matrices can change depending on the recorder type. PRINT ALL CONF prints only sub-
matrices relative to this recorder. This is true particularly for ANALOG and DIGITAL sub-matrices,
whose printed lines correspond to an existing hardware channel.
• For the MESSAGE sub-matrix, only lines with a non blank message are printed.
• Accessible passwords in the MISCEL sub-matrix are not printed.
• To provide the longest printer ribbon life, PRINT ALL CONF alternates the colors automatically:
- Black for heading
- Brown, purple, green and blue are alternatively used for the printing of parameter values.
• Printing formats take into account the smallest printing width, which can be defined by the user.
The following example represents a printing format you may use:
***ANALOG INPUT 15.55 15
TH
OCT 96***
AN# SENSOR RANGE EXT COMP FILTER LOW VAL HIGH VAL
01 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
02 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
03 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
04 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
05 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
06 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
07 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
08 RT D OHM 0/2000 0.0 5.0 0.00 2000.00
etc.
AN# STD MATH DIFF WITH BURN OUT LOW ADJ HIGH ADJ
01 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
02 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
03 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
04 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
05 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
06 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
07 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
08 SQUARE RO ANALOG #01 FIX HIGH 0.0 1.0
etc.
