Honeywell ECS Series Installation And Operation Guide

Installation 151455
3-5
3.3 Electrical Specifications
* Fully loaded system
3.4 Installing ECS-Series Cabinets
This section provides instructions on how to install the ECS series cabinets for surface or flush
mounting.
3.4.1 Preventing Water Damage
Refer to Section 3.1 when choosing a mounting location. Water damage to the fire system can be
caused by moisture entering the cabinet through the conduits. Conduits that are installed to enter the
top of the cabinet are most likely to cause water problems. Installers should take reasonable
precautions to prevent water from entering the cabinet. Water damage is not covered under warranty.
3.4.2 Surface Mounting the IFP-100ECS, IFP-1000ECS,
IFP-300ECS, IFP-2100ECS or ECS-LOC Cabinet
The Cabinets can be mounted on the wall surface by using the mounting holes in the back of the
cabinet (see Figure 3-5). The ECS-LOC Local Operating Console is a combination ECS-RVM Remote
Voice Module and its associated annunciator. The ECS-LOC is compatible with the Honeywell
Farenhyt Series panels, IFP-1000ECS, IFP-100ECS, IFP-300ECS, and IFP-2100ECS.
Table 3-1: ECS-50W AC Current Draw
Module Voltage
Standby
Current
*Alarm
Current
ECS-50W 25V 120V 60 Hz 350 mA 1100 mA
ECS-50W 25V 240V 50 Hz 200 mA 600 mA
ECS-50W 70V 120V 60 Hz 350 mA 1200 mA
ECS-50W 70V 240V 50 Hz 200 mA 600 mA
Table 3-2: ECS-125W AC Current Draw
Module Voltage
Standby
Current
*Alarm
Current
ECS-125W 25V 120V 60 Hz 300 mA 2200 mA
ECS-125W 25V 240V 50 Hz 250 mA 1250 mA
Table 3-3: ECS-DUAL50W AC Current Draw
Module Voltage
Standby
Current
*Alarm
Current
ECS-DUAL50W 25V 120V 60 Hz 190 mA 2380 mA
ECS-DUAL50W 25V 240V 50 Hz 200 mA 1260 mA
ECS-DUAL50W 70V 120V 60 Hz 190 mA 2470 mA
ECS-DUAL50W 70V 240V 50 Hz 200 mA 1310 mA
