ECS Series Emergency Communication System Installation Manual 151455
1-2
1.2 Features
ECS-Series
• Single enclosure for both Fire and Emergency Control System components.
• On-board supervised microphone
• Supports 25 Vrms or 70.7 Vrms speaker circuits using ECS-50W, ECS-INT50W or ECS-
DUAL50W. Supports 25 Vrms using ECS-125W.
• Voice Control Module (VCM) and Network Voice Control Module (ECS-NVCM)
- IFP-2100ECS or IFP-300ECS have support for one ECS-NVCM.
- Built in Digital Message Repeater
- 15 ECS Messages
• IFP-2000ECS, IFP-300ECS or IFP-2100ECS Systems have support for dual channel and backup
audio using the ECS-DUAL50W amplifier and ECS-50WBU back-up amplifier.
• SBUS Addressable Amplifier
- IFP-100ECS, IFP-300ECS or IFP-1000ECS Systems support a combination of up to eight ECS-
50W’s, ECS-125W’s or ECS-DUAL50W’s for a maximum of 1000 watts per system.
- IFP-2000ECS has support for up to 16 ECS-50W’s, ECS-125W’s or ECS-DUAL50W’s for a max-
imum of 2000 watts per system.
- IFP-2100ECS has support for up to 16 ECS-50W’s, ECS-125W’s, ECS-INT50W’s or ECS-
DUAL50W for a maximum of 2000 watts per system and up to 128 mappable speaker circuits.
• Local Operator Console (LOC)
- IFP-100ECS, IFP-300ECS, IFP-1000ECS, or IFP-2000ECS Systems can support up to seven
ECS-LOC's
- IFP-2100ECS Systems can support up to 15 ECS-LOC’s
• Mappable Speaker Circuits
- IFP-100ECS, IFP-300ECS or IFP-1000ECS Systems can support up to 64 mappable speaker
circuits using a combination of ECS-50W's, ECS-125W's, ECS-DUAL50W's and ECS-CE4's.
- IFP-2000ECS and IFP-2100ECS Systems can support up to 128 mappable speaker circuits
using a combination of the ECS-50W, ECS-125W, ECS-DUAL50W, ECS-INT50W and ECS-CE4.
• Backup Amplifier
- ECS-DUAL50W's are capable of providing 50 watts of backed up audio power with the addition
of the ECS-50WBU.
ECS-RVM Remote Voice Module IFP-100ECS, IFP-1000ECS,
IFP-2000ECS, IFP-300ECS, and
IFP-2100ECS
ECS-LOC Local Operating Console IFP-100ECS, IFP-300ECS, IFP-
1000ECS, and IFP-2000ECS
ECS-LOC2100 Local Operating Console IFP-2100ECS
ECS-DUAL50W / ECS-
DUAL50WB**
Dual 50W Amplifier IFP-100ECS, IFP-1000ECS,
IFP-2000ECS, IFP-300ECS, and IFP-
2100ECS
ECS-50WBU External Backup Amplifier IFP-100ECS, IFP-1000ECS, IFP-
2000ECS, and IFP-300ECS
ECS-INT50W 50 watt internal amplifier IFP-100ECS, IFP-1000ECS,
IFP-2000ECS, IFP-300ECS and IFP-
2100ECS
*All references to ECS-50W within this manual are applicable to the ECS-50WB.
**All references to ECS-DUAL50W within this manual are applicable to ECS-DUAL50WB.
Model Number Description Compatible With
