ECS Device Installation 151455

4-39

Figure 4-51 Connecting Multiple ECS-125Ws to the SBUS using ECS-VCM

Figure 4-52 Connecting ECS-125W to the SBUS using ECS-NVCM

Supervised

ECS-125W

ECS-VCM

ECS-125W

To next ECS-125W (Max 8)

Power Limited
