Periphery components for ESSER FACP
TI 798960.GB0 / 04.20 19
IQ8Quad with integrated alarm
device
Ready to operate
(green LED)
Alarm status
Fig. 4: IQ8Quad with integrated alarm device
General technical specifications
*3
Operating voltage : 8 V DC ... 42 V DC
Max. monitoring area : 110 m²
Max. monitoring height : 12 m
Air speed : 0 ... 25.4 m/s
Usage temperature : -20 °C ... +65 °C
Storage temperature : -25 °C ... +75 °C
Humidity :
≤ 95% rel. humidity (non-condensing)
IP rating: : IP 43 (with base + option)
Material : ABS
Colour : white (similar to RAL 9010)
Weight : approx. 145 g
Dimensions (with base) : Ø = 117 mm, H = 67 mm
