Periphery components for ESSER FACP
26 TI 798960.GB0 / 04.20
7 7
16 / 4
8
oder /
or
Art.-Nr. / Part No. 805574
Art.-Nr. / Part No. 805576
Fixing eyelets/description field (optional)
Insertable fixing eyelets
7
and cover ring
(Part No. 805574) for the mounting base, e.g. on an
installation box.
or
Insertable description field (Part No. 805576) e.g. for
displaying
8
the zone/detector number.
1
WAGO 243-204
(Ø 0.5 - 1.0 mm)
WAGO 273-104
(0.75 - 2.5 mm
2
)
9
Connection terminal, 3-pole (optional)
Up to two conventional connection terminals
9
can be
installed in the pre-installed mounts of the fire detector
base.
Recommendation:
243-204 WAGO (∅ 0.5 - 1.0 mm)
273-104 WAGO (0.75 - 2.5 mm
2
)
Fig. 8: Options
