Honeywell Evohome

10 evotouch
Multizone system with radiators2.3
Example: 6 zones, up to 8 zones are possible
evotouch
BDR91
Zone 2
Zone 4
Zone 5
Zone 6 ... 8
Zone 3
Boiler room
Zone 1
HR80
HR80
HR80
HR80
HR80
HR80
Notes
The internal room sensor of the • evotouch controller must be activated for zone 1
• Zone 1: HR80 internal room sensor not used
Optional boiler feedback: BDR91 relay module or OPENTHERM-Bridge•
