Honeywell Evohome

16 evotouch
Multizone system with underoor heating individual room sensor2.6
Example: 6 zones, up to 8 zones are possible
evotouch
BDR91
Zone 2
Zone 4
Zone 5
Zone 6 ... 8
Zone 3
Boiler room
Zone 1
HCF82
HCF82
HCF82
HCF82
HCF82
HCE80(R) /
HCC80(R)
Notes
The internal room sensor of the • evotouch controller must be activated for zone 1
Optional heat demand: BDR91 relay module or OPENTHERM-Bridge•
