H-SERIES GREEN CLASS NET METER
33 62-0424-02
NOTE: One set of current sensors equates to three sensors, one per phase. The
multiplier only applies when extra sets of current sensors are installed on one
meter. If you are using only one set of three current sensors, the multiplier is
not required.
Fig. 17. Three Phase Multiple-load Wiring Diagram.
LOAD SOURCE (LINE)
LINE VOLTAGE CURRENT SENSORS
A
B
C
N
C N B W B W B W
LOAD SOURCE (LINE)
A
B
C
N
LOAD A
LOAD B
CURRENT SENSOR LEADS
CURRENT
SENSOR
LEADS
LINE VOLTAGE LEADS
M34643
1
1
1
