H-SERIES GREEN CLASS NET METER
9 62-0424-02
3.0 METER TECHNICAL SPECIFICATIONS
Ordering Information: Define brand, class, input voltage, current sensor rating,
enclosure, protocols/options, and sensor type in the format A-BB-CCC-DDDD-E-FF-G-
HHH, where:
A = Brand: H for Honeywell
BB = designates Class: 320 (32) or 500 (50) meter
CCC = input voltage: (208, 480, 600, 120 volt for high voltage applications only)
DDDD = current sensor rating: (100, 200, 400, 800, 1600, 3200, 25HV)
E = enclosure: J = metal (type 1), R = non-metallic (rain tight) (type 4X)
FF= protocol option:
G = no package = “blank”
NSP= Single or Two Phase (Optional)
HHH= Sensor Type: kit=split-core, scs= solid-core, non-supplied blank”
Brand Class Voltage Amperage Enclosure Communication Protocol Current Sensor/Option Current Sensor/Option Current Sensor/Option
Example H 50- 208 100- J 01 -N- KIT
H50-208100-J01-N-KIT
Brand Honeywell
Class 500
Voltage 120, 208, 400 (380-415), 480, 600
Amperage 2HV, 100, 200, 400, 800, 1600, 3200
Enclosure J (JIC Steel), I (Interior only), R (Rain tight)
Communication
Protocol
01 (EZ-7, EZ-7 ETHERNET),
02 (MODBUS RTU, EZ-7 ETHERNET),
03 (BACNET MSTP, EZ-7 ETHERNET),
04 (EZ-7, MODBUS TCP/IP),
05 (EZ-7, BACNET IP),
06 (MODBUS RTU, MODBUS TCP/IP),
07 (LONWORKS TP,EZ-7 ETHERNET),
08 (LONWORKS TP, MODBUS TCP/IP),
09 (EX-7, EZ-7 ETHERNET WITH MODEM),
10 (EZ-7, MODBUS TCP/IP WITH MODEM),
11 (EZ-7, BACNET IP WITH MODEM)
Current Sensors/
Options
-N- (GREEN CLASS NET METER), KIT (Split Core), SCS
(Solid-Core), NSP (Single or Two phase Green Class Net
Meter - 2 element)
