H-SERIES GREEN CLASS NET METER
35 62-0424-02
9.0 LITHIUM BATTERY REPLACEMENT
INSTRUCTIONS
The Green Class Net kWh/Demand meter has a Lithium Battery Cell, which is used to
retain the contents of SRAM and the RTC during power outages. The battery has a life
expectancy of greater than 5 years.
Fig. 19. Battery Specifications at 25 Degrees Celsius.
Only replace battery with Panasonic part number CR2032 only. Use of another
battery may present a risk or explosion. See owners manual for safety
instructions. Internal circuit card components are extremely sensitive to
electrostatic discharge. Be careful not to touch internal circuitry prior to
discharging any static buildup on your person. To discharge yourself, touch a
grounded metal object such as conduit or a metal enclosure exterior.
Nominal Working Voltage 3 Vdc Output
Nominal Current Capacity 225 mAHr
Cell Chemical Manganese Dioxide Lithium
Operating Temperature Range -30 to +60 Degrees Celsius
Manufacturer Panasonic
Manufacturer’s Part Number CR2032
