Honeywell H Series - 8.0 PREVENTATIVESCHEDULED MAINTENANCE; Maintenance Requirements Overview

H-SERIES GREEN CLASS NET METER
62-0424-02 34
Fig. 18. Single Phase Multiple-load Wiring Diagram.
8.0 PREVENTATIVE/SCHEDULED
MAINTENANCE
The unit is shipped in a calibrated and fully functional tested condition. Since the unit is
factory-calibrated using proprietary firmware algorithms, no internal unit adjustments
are necessary.
This unit contains no internal adjustments, so no preventative or scheduled
maintenance is required.
No cleaning or decontamination procedures are required for this instrument.
CURRENT SENSORS
