H-SERIES GREEN CLASS NET METER
62-0424-02 42
12.0 MODBUS POINT MAPS
Modbus Integer Registers:
Address Reg Description Units
Green
Net
Meters
40001* 2 Energy delivered kWh Pulse R/W
40003 2 Energy received kWh Pulse R/W
40005 2 Reactive energy delivered kVARh Pulse R/W
40007 2 Reactive energy received kVARh Pulse R/W
* To clear single meter kWh/kVARh, set multiple points at 40001 for 8 points with data
set to 0000 0000 0000 0000 0000 0000 0000 0000. Jumper J6 must be closed.
Modbus Float Registers:
Address Reg Description Units
Green
Net
Meters
41001** 2 Energy delivered kWh R/W
41003** 2 Energy received kWh R/W
41005** 2 Reactive energy delivered kVARh R/W
41007** 2 Reactive energy received kVARh R/W
41009 2 Real power kW R
41011 2 Reactive power kVARh R
41013 2 Apparent power kVARh R
41015 2 Power factor % PF R
41017 2 Current total Amps R
41019 2 Current average Amps R
41021 2 Voltage line-neutral Volts-N R
41023 2 Voltage line-line Volts-L R
41025 2 Frequency Hz R
41027 2 Phase angle Degree R
41029 2 Real power, phase A kW R
41031 2 Real power, phase B kW R
41033 2 Real power, phase C kW R
41035 2 Reactive power, phase A kVAR R
41037 2 Reactive power, phase B kVAR R
41039 2 Reactive power, phase C kVAR R
41041 2 Apparent power, phase A kVA R
