Honeywell H Series User Manual

H-SERIES GREEN CLASS NET METER
43 62-0424-02
41043 2 Apparent power, phase B kVA R
41045 2 Apparent power, phase C kVA R
41047 2 Power factor, phase A % PF R
41049 2 Power factor, phase B % PF R
41051 2 Power factor, phase C % PF R
41053 2 Current, phase A Amps R
41055 2 Current, phase B Amps R
41057 2 Current, phase C Amps R
41059 2 Voltage, line to neutral, phase A-N Volts-N R
41061 2 Voltage, line to neutral, phase B-N Volts-N R
41063 2 Voltage, line to neutral, phase C-N Volts-N R
41065 2 Voltage, line to line, phase A-B Volts-L R
41067 2 Voltage, line to line, phase B-C Volts-L R
41069 2 Voltage, line to line, phase C-A Volts-L R
41071 2 Phase angle, phase A Degree R
41073 2 Phase angle, phase B Degree R
41075 2 Phase angle, phase C Degree R
41077 2 Reserved
41079 2 Reserved
41081 2 Reserved
41083*** 2 External Input 1 Pulse R/W
41085*** 2 External Input 2 Pulse R/W
** To clear single meter kWh/kVARh, set multiple points at 41001 for 8 points with data set to
0000 0000 0000 0000 0000 0000 0000 0000. Jumper J6 m
***
External inputs are standard on Class Net Meters and optional on Class 3400 meters (Part of
Expanded Feature Package).To clear Auxiliary Inputs, set multiple points at 41083 or 41085 for
2 points with data set to 0000 0000. Jumper J6 must be closed.
BACnet Object Descriptors:
ID
BACnet
Object Description Units
BACnet
Property
Green
Net
Meters
1 Analog Input Energy delivered kWh Present Value R
2 Analog Input Energy received kWh Present Value R
3 Analog Input Reactive energy delivered kVARh Present Value R
Modbus Float Registers:
