H-SERIES GREEN CLASS NET METER
21 62-0424-02
6.5 Main Power & Current Sensor Wiring Diagram
Fig. 9. Three Phase - Three Wire or Three Phase - Four Wire Installation Diagram
Fig. 10. Single Phase, Three Wire Installation Diagram
LINE VOLTAGE CURRENT SENSORS
ØA ØB ØC
W B W B W B
A B C N
LOAD SOURCE
A
B
C
N
TERMINAL BLOCK LOCATED INSIDE E-MON D-MON
®
METER
Ø Ø
Ø
M34291
RECOMMENDED FUSES OR CIRCUIT BREAKER PER THE NATIONAL
ELECTRICAL CODE (METER LOAD 6VA.)
NEUTRAL NOT USED IN DELTA SYSTEM.
SPLIT-CORE CURRENT SENSORS. INSTALL ACCORDING TO
INSTRUCTIONS.
1
2
3
1
1
1
2
3
3
3
LINE VOLTAGE CURRENT SENSORS
ØA
ØB
ØC
W B W B W B
A B N
LOAD SOURCE
A
N
B
Ø
Ø
M34842
TERMINAL BLOCK LOCATED INSIDE METER
RECOMMENDED FUSES OR CIRCUIT BREAKER PER THE NATIONAL
ELECTRICAL CODE (METER LOAD 6VA.)
CURRENT SENSORS INSTALLED ACCORDING TO INSTRUCTIONS.
INSTALL JUMPER WIRES.
1
2
3
1
1
3
2
2
ØC
3
