Introduction | 25
800-18161 - A - 06/2014
HBD2PR1
Dimensions
Figure 1-3 HBD2PR1 Camera Dimensions
Components
Figure 1-4 HBD2PR1 Camera Components
3 Dome camera enclosure
4 LAN Network port to connect to standard Ethernet.
5 12 V DC Connect 12 V DC
Table 1-2 H2D2PR1 Camera Components
Name Function
In millimeters
