800-18161 - A - 06/2014
B
Specifications B
Table B-1 Specifications
Operational
Video Standard NTSC / PAL
Scanning System Progressive
Image Sensor 1/3" 2 Megapixel progressive scan Exmor CMOS
Effective Pixels 1920 (H) × 1080 (V)
Minimum Illumination 0.5 Lux @ F1.6 (Color); 0 Lux @ F1.6 (IR LEDs on)
Maximum IR LEDs
length
H2D2PR1: 20 m
HBD2PR1: 30 m
Video Output N/A
S/N Ratio More than 50 db
Gain Control Auto / Manual
Electronic Shutter
Speed
Auto / Manual (1/3 ~ 1/10000s)
Lens Type 3.6 mm Fixed, F1.6
Horizontal Angle of
View
H2D2PR1: 88° (53°)
HBD2PR1: 88° (53°/39°)
Mount Type Board-in type
White Balance Auto / Day / Night / Customized
Day/Night Auto(ICR) / Color / B&W
Backlight
Compensation
BLC/DWDR
Exposure Mode Manual / Low noise / Low motion blur / Auto
Ranges from 1/3 to 1/10000
Video Frame Rate PAL: Main Stream (1920 x 1080 @ 25fps),
Sub Stream (704 x 576 @ 25fps)
NTSC: Main Stream (1920 x 1080 @ 30fps),
Sub Stream (704 x 480 @ 30fps)
