Honeywell HF680 User Manual

150 HF680 Series User Guide
HF680E
[
HF680M
[
Parameter Specification
Mechanical
Length 2.91 in. (74mm)
Width 2.87 in. (73mm)
Height 2.66 in. (67.5mm)
Weight 5.6 oz.±0.3 (140g±10)
Electrical
Input Voltage 5 VDC ±0.5V
Operating Power 2.0W (400mA @ 5V)
Standby Power .85W (170mA @ 5V)
Host System Interfaces USB, RS-232
Environmental
Operating Temperature 14°F to 122°F (-10°C to 50°C)
Storage Temperature -40°F to 140°F (-40°C to 60°C)
Humidity 0 to 95% non-condensing
Drop Designed to withstand 3.3 ft. (1.5m) drops
Light Levels 0 to 100,000 lux
Image Size 1280 x 800 pixels
Scan Performance
Scan Angle 47° horizontal, 30° vertical
Contrast 20% minimum reflectance difference
Pitch, Skew 60°, 70°
Parameter Specification
Mechanical
Length 3.5 in. (88.9mm)
Width 2.88 in. (73.1mm)
Height 1.94 in. (49.3mm)
Weight 2.03 oz.±0.2 (57.5g±5)
Electrical
Input Voltage 5 VDC ±0.5V
Operating Power 2.0W (400mA @ 5V)
Standby Power .85W (170mA @ 5V)
Host System Interfaces USB, RS-232

Honeywell HF680 Specifications

General

Scan Pattern	Area Image (1280 x 800 pixel array)
Humidity	0% to 95% relative humidity, non-condensing
Standby Power	0.45 W (90 mA @ 5 VDC)
Light Levels	0 to 100, 000 lux
Decode Capability	Reads standard 1D, PDF, 2D, Postal and OCR symbologies
Interface	USB, RS232, Keyboard Wedge
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Drop	Designed to withstand 1.5 m (5 ft) drops
Input Voltage	4.0 V DC to 5.5 V DC
