152 HF680 Series User Guide
Guaranteed Performance
HF680E
Typical Performance
Focus
Symbology
Near
Distance
Far
Distance
5 mil Code 39 in. 0.39 2.76
mm 10 70
6.7 mil PDF in. 0 3.15
mm 0 80
10 mil Data Matrix in. 0.2 3.15
mm 5 80
13 mil UPC-A in. 0 6.5
mm 0 165
20 mil Code 39 in. 0 8.66
mm 0 220
20 mil QR Code in. 0 7.09
mm 0 180
*Resolution: 1D: 3mil
2D: 6.7 mil
*Performance may be impacted by barcode qu ality.
Focus
Symbology
Near
Distance
Far
Distance
5 mil Code 39 in. .59 4.53
mm 15 115
6.7 mil PDF in. .59 4.92
mm 15 125
10 mil Data Matrix in. .59 4.13
mm 15 105
13 mil UPC-A in. 0 8.86
mm 0 225
20 mil Code 39 in. 0 12.4
mm 0 315
20 mil QR Code in. .59 8.86
mm 15 225
