Operators manual underground gas pressure reducing station
Type: HON COCON 13
Page 22
4.2.1‐Installationofcartridge

Thisparagraphdescribestheinstallationofthecartridgeinthecasing.Thecartridgecanbereplacedwithaspare
cartridge(adjusted)within20minutes.

Toinstallthecartridgeinthecasing,proceedasfollows:

Remark:Takecareofyourbackwhilelifting,wheninstallingand
removingthecartridge.

- Liftthecartridgebythehandles.

- Lowerthecartridgeinthecasing,thecartridgeisguidedbythethreadedrods.

- Thecartridgehastobefittedwithitsmeasuringtubepointedtotheoutletside.

‐ FixthecartridgewiththefournutsM16/M24)*tothe
body.Theunitisnowfixedintoposition.

4.2.2‐Emergency‐stop

Thereisanemergencystopcontrolbuttonontheslamshutvalvecontroller,whichcanbeusedwhenrequired,toput
thecartridgeimmediatelyoutofoperation.

Tousethisemergencystopbutton,proceedasfollows:

- Openthe
casingcover.

‐ Thesilvercolouredbuttonislocatedonthesideoftheslamshutvalvecontroller.

‐ Presstheemergencystopcontrolbutton.Thiscausesthevalvetoclosedownthegassupplytotheregulator.

Anactivatedvalvecanberecognisedbytheraisedredbutton,whichis
locatedunderthetransparentcap,onthe
shutoffrelay.

Aftercorrectingthemalfunction,youcanresettheemergencystopcontrolbuttonbyfirstpushingtheredbutton
halfwaydown(thisallowsthebypasstoequalisethepressure).Afterequilibriumhasbeenachievedthenpressthe
buttonalltheway
down,resettingthevalve.

Takenote: oncealowertripfunctionisinstalledandset,theoutletpressureshouldbeabovethe
 lowertripvalue(+relatchingdifference)toenablereset


















