Operators manual underground gas pressure reducing station
Type: COCON 13
Page 7

2.2WhatistheHONCOCON13

TheHONCocon13isacompleteself‐containedundergroundgasregulatingstationforthereductionofgaspressure.
Thestationcanbecompletelyburiedorinstalledabovegroundinanareamuchsmallerthanaconventional
regulatingstation.
Thestationensuresreliablegassupplyataconstantpressureindependent
ofthegasconsumption.

Thestationhavingallessentialelementsofaconventionalpressurereductionstationisdesignedforuseongas
distributionandindustrialapplications.
Onlyaveryrestrictedareaisrequiredforinstallingthestation.
Theworkingelementsarecontainedinaremovablecartridgeretainedbyasimpleclosing
construction.
Allbeinghousedinasteelbodythatisinstalledundergroundintothegasmain.
Abovegroundisaventstack,whichcontainsventpipesforatmosphericreferenceandthereliefvalve.

TheHONCoconissuppliedpre‐assembledintoaskidpackage,whichconsiderablyreducestheon‐site
installation
time.

Thestationismadeofsteel,aluminum,bronzeandsynthetics.Thestationcanbeproducedinothermaterialsupon
request.



2.3Construction

Remark: Forthelocationofthepartsofthegaspressurereducingstation,mentionedinthetext,wereferto
illustration2.4.1.

Theshortnumbersbetweenthebrackets,whicharementionedinthetext,
arepositionnumbersofthepartsinillustration2.1.

Thetopofthestationislocatedafewcentimetersaboveoratgroundlevel.Dependingonthecompositionofthe
soil,aconcretefoundation(plate)underthestationmaybeneeded.


ThegasregulatingstationHONCOCON13consistsoftwoparts:

‐ Thebody.
‐ Thegasregulatingandsafetyunit.(Cartridge)

Remark: The"gasregulatingandsafetyunit"willbereferredtoasthecartridgeintherestofthe
manual.











