4.7.1‐Uppersealring

Theuppersealringissituatedinthegrooveonthecasing(Illustration4.3).


   Illustration4.7'Uppersealrings'


Toreplacetheuppersealring,proceedasfollows:

- Removethesealringfromthegroove.

‐ Cleanthegroovewithasolvent,whichdoesnotaffectthecasingmaterial.

Remark:Makesurethatthesealringissufficientlygreasedwithalowviscosity,
gasresistantgel.(We
recommendParkerSuper‐O‐Lube)

‐ Presstheo‐ringinthegroove.

4.7.2‐Lowersealrings

Thetwolowersealringsaresituatedinthegroovesdirectlyabovethedustfilter.

Thereplacethelowersealrings,proceedasfollows:

- Removebothsealringsfromthegrooves.

‐ Cleanbothgrooveswithasolvent,
whichdoesnotaffectthecartridge'smaterial.

Remark:Makesurethatthesealringsaresufficientgreasedwithalowviscosity,gasresistantgel(We
recommendParkerSuper‐O‐Lube).

- Slidebothringsfromthebottomofthecartridgeupwards,untiljustunderbothgrooves.

- Presstheupperringinthegroove.

‐ Pressthelowerringinthegroove.


