Contents
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot 2
Contents
1 Generalconsiderations 4
1.1 Aboutthisusermanual 4
1.2 Aboutthesafetynotices 5
2 Description 7
2.1 Intendeduse 7
2.2 Devicemodels 8
2.3 Labels/Markings 9
2.4 Identifyingthedevice 10
2.5 Layoutandoperation 12
2.6 Technicalspecifications 17
3 Safety 21
3.1 Basicsafetyrules 21
3.2 Requirementsconcerningtheworkforce,personalprotectivegear,workplaces 22
4 Basicsforinstallingthedeviceinapipe 25
4.1 Installationexamples 25
4.2 Meterruncharacteristics 27
4.3 Operatingandmeasuringlines 29
4.4 Alternativeapplicationexample:Activemonitorregulator 30
5 Transport,installationandstart‐up 32
5.1 Transportingthegaspressureregulator 32
5.2 Installingthegaspressureregulator 34
5.3 Installingthedeviceconnections 35
5.4 Checkingthesystemforleaks 36
5.5 Startingupthegaspressureregulator 38
6 Adjustingthesettingsofthedevice 40
6.1 Settingthetargetpressure 40
7 Malfunctions 42
7.1 Malfunctions 42
8 Maintenance 44
8.1 Maintenanceschedule 44
8.2 Preparingforthemaintenance 45
8.3 Startingmaintenance 45
8.4 Maintainingtheactuatorassembly 50
8.4.1 MaintainingtheHONR100NGactuatorassembly 50
8.5 Maintainingthepilot 62
8.5.1 MaintainingtheHONP095NG‐HPpilot 62
8.5.2 MaintainingtheHONP095NG‐MPpilot 65
8.5.3 MaintainingtheP095pilot’sadjustablerestrictor 75
8.6 Completingthemaintenance 76
