Transport,installationandstart‐up
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  32
5 Transport,installationandstart‐up

Topic Page
Transportingthegaspressureregulator 32
Installingthegaspressureregulator 33
Installingthedeviceconnections 35
Checkingthesystemforleaks 36
Startingupthegaspressureregulator 37

5.1 Transportingthegaspressureregulator

Riskofseriousinjuryposedbyheavyloadswhenusingcranesfortransportation
Transportingheavydevicesorcomponentswithacranemayresultinseriousimpactand
crushinjuriesiftheloadsstartmovinginanuncontrolledmanner.
 Loadsmayonlybetransportedwithacranebyadulyqualifiedperson.
 Markingsandinformationaboutthecenterofgravityoftheload(ifapplicable)mustbe
observed.
 Loadsmayonlybemovedundersupervision.


Riskofseriousinjuryintheeventthatloadhandlingattachmentsbreakwhileholdinga
suspendedload
Heavyloadspickeduportransportedwithhoistingandslinginggearmayresultinserious
impactandcrushinjuriesiftheloadhandlingattachmentsfail.
 Onlyfastenthedeviceatthepositionsintendedforthetransport.
 Theload‐bearingcapacityoftheappropriatehoistingequipmentmustcorrespondat
leasttotheweightoftheloadtobetransported.
 Alwaysstandclearofsuspendedloads.
 Ensurethatnopersoniswithinthedangerzone.

Amobileworkshopcraneissuitableforuseashoistingequipment.Apalletjackorforkliftis
alsosuitableforintraplanttransportation.
Thefollowingareadequateforuseasslings:
 Ropes
 Belts
 Chains
Thehoistingequipmentandslingsmustmeetthefollowingcriteria:
 Theloadcapacitymustbesufficientforthegaspressureregulator’sweight.
 Thehoistingheightisadequateforthemountingpositionattheinstallationsite.

Contents
Heavytransportunits
Suspendedloads
Selectingthehoisting
equipmentandslings
