Description
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  9
2.3 Labels/Markings

Illegibleinformationonthedeviceposesariskofinjuryduetoresultingerroneousopera‐
tion,use,orinstallation.
Labels,aswellasinscriptionsandstampingonthedevice,caneventuallybecomesoiledor
otherwiseunrecognizabletosuchanextentthatuserswillnotbewarnedeffectivelyof
hazardsandmaybeunabletofollowrequiredoperatinginstructions.Thiswillposeariskof
injury.
 Makesuretoalwayskeepallrelevantlabelsingoodconditionsothattheywillbeeasily
legible.
 Immediatelyreplacedamagedandmissinglabels.

Thefollowinglabels/markingscanbefoundonthefrontoftheactuatorassembly:
Figure No. Meaning
1 Nameofthedevice
2 Nominalsizeandpressurerating
3 Bodysectionmaterials
4 Arrowindicatingthedirectionofflow

Thefollowinglabels/markingscanbefoundatthetopoftheactuatorassembly:
Figure No. Meaning
1 ANSIpressurerating
2 Material

Illegiblelabels
Labelsonthe
HON R100NGactuator
assembly
