Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  76
Figure Step Description
3
 Removetheassembly (1)withthe
needle.
 ReplacetheO‐ring (2)withanew,
greasedO‐ring. 
4
 Slidetheassembly (1)withtheneedle
backintotheadjustablerestrictorhous‐
ing.
 Putthesleevenut (2)backinplaceand
tightenit.
 Installtheadjustablerestrictorbackon
thepilot.

Proceedasfollows:
 Completingthemaintenance(seepage76)
 Maintainingtheactuatorassembly(seepage50)
 Storingthedevice(seepage78)


8.6 Completingthemaintenance
Whenconductingworkinvolvingthepipework,pleasealwaysobservethefollowing:
Figure Description
Donottwistthepipeconnectionsintheassemblies.
Useasecondspannerwrenchforsecuringwhen
looseningandtighteningpipejoints.

Nexttask
Protectingthepipecon‐
nectionsfrombeing
twisted
