Description
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  8
2.2 Devicemodels
GaspressureregulatorsconsistingofanHON R100NGregulatorunitcombinedwithan
HON P095NGpilotareavailableinanumberofversions.Theseversionsarederivedfromthe
variouspossiblecombinationsbetweenthevariouspilotandactuatorassemblyversions.

TheHON R100NGactuatorassemblyisavailableintwodesigns.Inadditiontothetwobasic
configurations–thestandardversionandthefail‐openversion–anactivemonitorregulator
circuitcanbesetupaswell.Thetablebelowshowsthedifferentcharacteristicsofthese
designs:
HON R100NG HON R100NG‐FO
Standardversion 
fail‐closed fail‐open
1",2",3",4",6",8"
nominalinletsizes
1",2",3",4",6",8"
nominalinletsizes
ANSIclass150toclass600pressureratings ANSIclass150toclass600pressureratings

Thefollowingtableshowswhichmodelsareavailable:
Description Design Setpointrange
HON P095NG‐MP
Medium‐pressuremodel
(mediumpressure)
0.5to15bar 
(2.25to217psi)
HON P095NG‐HP
High‐pressuremodel
(highpressure)
10to60bar
(145to860psi)

Theonlystructuraldifferencebetweenthetwoversionsistheupperdiaphragmunit’sdesign,
meaningthatyoucanswitchbetweentheversionsbychangingthediaphragmunit. 

Thetechnicalspecifications(seepage17)andtheMaintenance(seepage44)section,aswell
asthesparepartslistsandsparepartsdrawingsintheappendix(seepage81),describeall
thegaspressureregulatorversionsandallthemodelscorrespondingtothestandardforthis
devicetype.Special‐purposeversionsareidentifiedwith“SO”intheinspectioncertificate,
whichisincludedwiththegaspressureregulator.
TheremainingsectionsinthisusermanualmostlyusetheversionwiththeHON P095NG
pilotasareference.However,otherversionsandmodelswillbecoveredspecificallyaswell
whenthereareimportantdifferencesthatneedtobepointedout. 
Ifyouhavetroubleunderstandingtheinformationinthisdocumentation,contactthemanu‐
facturerwithoutfailbeforestartinganyworkonthedevice.



Gaspressureregulator
versions
HON R100NGactuator
assemblymodels
HON P095NGpilotmod‐
els
Versionsanddesignsin
thisusermanual
