Description

UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  7

2 Description



Topic Page

Intendeduse 7

Devicemodels 7

Labels/Markings 8

Identifyingthedevice 10

Layoutandoperation 12

Technicalspecifications 17



2.1 Intendeduse

HON R100NGgaspressureregulatorsfeaturinganHON P095NGpilotcanbeusedtomain‐

taintheoutletpressureofagasconstantwithinaregulatinglineregardlessoftheinfluence

ofdisturbancevariablessuchasinletpressurechangesand/ordischargechanges.Inaddition,

thesegaspressureregulatorscanbeusedtoimplementanactive‐monitorregulatorconfigu‐

ration.Itcanbeusedintransferstationsofgastransportationnetworks,inpowerplantsand

industrialplants.HON R100NGgaspressureregulatorsfeaturinganHON P095NGpilotare

suitableforusewithnaturalgasordry,non‐aggressiveindustrialgases.

Note:Theutilizationlimitsofthedevicewithregardtothemedium,operatingpressureand

operatingtemperaturecanbegatheredfromthetypeplateattachedonthedeviceorthe

technicalspecifications.

Theuseunderdifferentoperatingconditionsmustbecoordinatedinconsultationwiththe

manufacturer.



Pleaseobservethefollowinglimitationsofuse:

 Donotusethedeviceforanymediaotherthanthosementionedintheintendeduseor

thosediscussedwithandapprovedbythemanufacturer.

 Donotusethedeviceinanyinstallationpositionotherthantheonedocumentedin

thisusermanual.

 Donotusethedeviceagainstthedirectionofflowspecifiedonthedeviceandinthe

usermanual.

 Whenreplacingdefectiveparts,onlyuseoriginalsparepartsormanufacturer‐approved

standardparts.

 Donotattempttomodifyorremodelthedeviceonyourown.



Contents

Intendeduse

Limitationsofuse
