Basicsforinstallingthedeviceinapipe
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  30
4.4 Alternativeapplicationexample:Activemonitorregulator
Thearrowsonthepipesshowthedirectionofflow.
Front:

Back:

Sectionalview

Thenumbershavethefollowingmeaning:
No. Meaning
1 HON R100NGactuatorassemblywithHON P095NG pilot(monitorregulatorunit)
2 HON R100NG‐FOactuatorassemblywithHON P095NG pilot(activeregulatorunit)
3 Outletpressuremeasuringline
Overview
