UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  75
Figure Step Description
45 Screwthecap(1)backon.

Proceedasfollows:
 Maintainingtheadjustablerestrictor(seepage75)
 Completingthemaintenance(seepage76)
 Maintainingtheactuatorassembly(seepage50)
 Storingthedevice(seepage78)


8.5.3 MaintainingtheP095pilot’sadjustablerestrictor
Observethefollowingcleaninginstructions:
 Beforeassembly,allpartsmustbecleanedinordertoremoveanyforeignparticles
(swarf)andsoiling.
 Ifscrews,bolts,orwashersarereplacedwithidenticalnewparts,anyoilonthesenew
partsmustfirstberemoved.

Proceedasfollows:
Figure Step Description
1
Unscrewtheadjustablerestrictor (1)from
thepilot.
2 Unscrewthesleevenut (1)andremoveit.
Nexttask
Cleaning
Maintainingtheadjusta‐
blerestrictor
