Honeywell HON R100NG Series User Manual

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  62
8.5 Maintainingthepilot

Topic Page
MaintainingtheHONP095NG‐HPpilot 62
MaintainingtheHONP095NG‐MPpilot 65
MaintainingtheP095pilot’sadjustablerestrictor 75

8.5.1 MaintainingtheHONP095NG‐HPpilot

Crushandimpacthazardposedbycomponentsfallingortopplingoveraccidentally.
Whenworkingwithheavycomponentsthathavebeenremovedorareyettobeinstalled,
injurymayresultifthecomponentsstartmovinginanuncontrolledmanner,e.g.,fall down
fromtheworkingsurfaceortoppleover.
 Placeremovedcomponentsexclusivelyonlevel,horizontalworkingsurfaceswithenough
load‐bearingcapacity.
 Ifnecessary,secureremovedcomponentssothattheywillnotfallortoppleover.
 Weartherequiredpersonalprotectiveequipment.
 Exercisecautionwhenperformingtherelevanttasks.

Observethefollowingcleaninginstructions:
 Beforeassembly,allpartsmustbecleanedinordertoremoveanyforeignparticles
(swarf)andsoiling.
 Ifscrews,bolts,orwashersarereplacedwithidenticalnewparts,anyoilonthesenew
partsmustfirstberemoved.

Observethetighteningtorquesbelowwhenfollowingtheinstructionsinthissection:
Part Tighteningtorque Step
Screws
47 Nm 42

Proceedasfollows:
Figure Step Description

1‐33
AsindicatedinMaintainingthe
HON P095NG‐HPpilot.
34
Takethediaphragmunitforthesecond
pressurestage.Unscrewtheupperdia‐
phragmplate(1)andthehexnut(2)from
thepin(3). 
Contents
Fallingcomponents
Cleaning
Tighteningtorques
Maintainingthe
HON P095NG‐HPpilot
