Honeywell HON R100NG Series User Manual

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  61

If… then…
Themagneticringisrestingovertheposition
indicator’shousinginthepositionshowninstep4
proceedwithstep6.
ThemagneticringisNOTrestingovertheposition
indicator’shousinginthepositionshowninstep
4,butisinsteadinahigherorlowerposition
proceedwithstep5.

Figure Step Description
5
Removethemagneticringfromthe
positionindicator’shousing,turnit180°,
andplaceitbackoverthehousing.
6
Placethesightglass(2)andthecoverring
(1)backonthepositionindicator’shous‐
ing.Makesurethatthemagneticringstays
intherequiredposition.
7 Installtheretainingring(1).

Dependingonwhatyouwillbedoingnext,proceedasindicatedintherelevantsection:
 Completingthemaintenance(seepage76)
 Maintainingthepilot(seepage62)
 Storingthedevice(seepage78)

Nexttask
