Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  74
Figure Step Description
40
Putthespringhousingbackinplace,
Tightenthescrews(1),includingthe
washers,inacriss‐crosssequence.Ob‐
servethetighteningtorqueinformation
providedinthetablebeforethissection.
41
Insertthecompressionspring(2)andthe
springplate(1)backin.
42
Takethelocknut.ReplacetheO‐rings(1,2)
withnew,lubricatedO‐rings.
43
Screwthelocknut(1)backinplaceallthe
way.
44
Screwthesetscrew(1),includingthehex
nut,backin.
