Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  73
Figure Step Description
35
Removethewasher(1)andthelower
diaphragmplate(2).
36 Replacethediaphragmwithanewone.
37
Putthelowerdiaphragmplate(2)andthe
washer(1)backinplace.
38
Screwthehexnut(2)andtheupper
diaphragmplate(1)backonthepin(3).
Usethreadlockerasspecifiedinthelistin
theappendix.
39
Insertthediaphragmunit(1)backintothe
secondpressurestage’shousing.
