Honeywell HON R100NG Series User Manual

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  72
Figure Step Description
30 Puttheretainingring(1)backinplace.
31 Screwthegrommetnut(1)backon.
32
Turnthehousingover.Insertthevalve
rod’scompressionspringandthevalverod
(1)backintotheguide.
33
ReplacetheO‐ring(1)withanew,greased
O‐ring.
34
Takethediaphragmunitforthesecond
pressurestage.Unscrewtheupperdia‐
phragmplate(1)andthehexnut(2)from
thepin(3). 
