Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  77
Proceedasfollows:
Figure Step Description
1
Usetheconnectingplate(1)tosecurethe
pilotontheactuatorassembly.
2
Reinstallallthelines(1,2,3,4)youre‐
movedpreviouslyonthepilot.
3
Reinstallallthelinesyouremovedprevi‐
ouslyontheactuatorassemblyandthe
pipes.
Result:
Thepilotisnowinstalledontheactuator
assemblyandinthegasregulatingline.

Toinstall,followthesamestepsforremovalbutinoppositeorder.PleaserefertoStarting
maintenance(seepage45)forinformationonhowtoremovethepilotandtheactuator
assembly.

Proceedasfollows:
Checkingthesystemforleaks(seepage36)

Installingcomponents
Nexttask
